Triumph T10 Tina
| Specification | Details |
|---|---|
| Bore | 50.4 mm (1.984 in.) |
| Stroke | 50.0 mm (1.969 in.) |
| Compression Ratio | 7:1 |
| Engine Capacity | 99.75 cc (6.1 cu. in.) |
| Ignition Timing | 3/32 in. (2.4 mm) B.T.C., 22° B.T.C. |
| Contact Breaker Gap | 0.018 in. (0.45 mm) |
| Spark Plug | Champion N.4 |
| Spark Plug Gap | 0.030 in. (0.75 mm) |
| Carburetor Make and Type | Amal Type 32 |
| Main Jet | 95 |
| Needle Jet | 0.105 |
| Needle Position | 3rd |
| Throttle Slide | 3/4 |
| Pilot Jet | 15 |
| Fuel/Oil Ratios | 50 cc (with self-mixing oil) to 1 gallon |
| Fuel Tank Capacity | 6.7 gallons (6.7 litres) |
| Rear Hub Capacity | 50 cc |
| Bulb Sizes | Front: 6-volt 18/18 watt, Rear: 6-volt 3 watt |
| Wheel Size | 3.50x8 |
| Tyre Pressure (Front) | 12 lbs./sq. in. |
| Tyre Pressure (Rear) | 16 lbs./sq. in. |
| Dimensions | Rear Height: 38 in., Width: 24 in., Length: 68 in. |
| Weight | 150 lbs. |
